M4H-M-GEARED
MOTOR
|
|
|
▶
Possible to product for needs of ratio beside
bellow chart
아래 표 이외에 감속비 요구 사항
제작 가능
|
|
|
|
MOTOR
SPECIFICATION
|
| DESCRIPTION |
CURRENT |
SPEED |
TORQUE |
OUTPUT |
EFF |
| A |
RPM |
g-cm |
W |
% |
| NO
LOAD |
12V |
0.16 |
7200 |
|
|
|
|
24V
|
0.080
|
7000
|
|
|
|
| AT
MAX.EFF |
12V |
0.32 |
5330 |
34.6 |
1.89 |
49.58 |
|
24V
|
0.22
|
5690
|
42.17
|
2.46
|
46.65
|
| AT
STALL |
12V |
0.90 |
|
129 |
|
|
|
24V
|
0.70
|
|
175
|
|
|
|
|
|
|
D.C
12V
|
|
|
|
D.C
24V |
|
GEARED
MOTOR SPECIFICATION
|
| RATIO |
V |
1/37 |
1/50 |
1/62 |
1/73 |
1/86 |
1/100 |
1/125 |
1/150 |
1/180 |
1/200 |
1/255 |
1/250 |
1/280 |
1/315 |
| NO
LOAD |
12V |
194 |
144 |
116 |
98 |
83 |
72 |
57 |
48 |
40 |
36 |
32 |
28 |
25 |
22 |
|
24V
|
189
|
140
|
112
|
95
|
81
|
70
|
56
|
46
|
38
|
35
|
31
|
28
|
25
|
22
|
|
AT MAXEFF
|
12V
|
144
|
106
|
86
|
73
|
62
|
53
|
42
|
35
|
29
|
26
|
23
|
21
|
19
|
17
|
|
24V
|
153
|
113
|
91
|
78
|
66
|
57
|
45
|
38
|
31
|
28
|
25
|
22
|
20
|
18
|
| TORQUE(kg-cm) |
12V
|
0.9
|
1.1
|
1.4
|
1.6
|
1.9
|
2.2
|
2.8
|
3.4
|
4.0
|
4.5
|
5.1
|
5.6
|
6.3
|
7.1
|
|
24V
|
1.1
|
1.3
|
1.7
|
2.0
|
2.3
|
2.7
|
3.4
|
4.1
|
5.0
|
5.5
|
6.2
|
6.9
|
7.7
|
8.7
|
|
